There is no best map projection, only a best projection for a particular job. Ships navigate on the Mercator projection, because a constant compass course is a straight line on it; pilots use the Lambert conformal conic, on which a straight line closely follows the shortest route; national topographic maps use the transverse Mercator, often through the 60-zone Universal Transverse Mercator (UTM) grid; census, climate and other statistical maps need an equal-area projection such as Albers for a country or Mollweide and Equal Earth for the world; polar maps use the stereographic projection; maps of distance from one place use the azimuthal equidistant, as on the UN emblem; and general world wall maps use a compromise such as the Winkel tripel. Each choice follows from how a projection is built and which property it keeps.
Building a Projection in Four Decisions: Lambert's 1772 Toolkit
The modern theory of choosing a projection begins with Johann Heinrich Lambert, an Alsatian polymath who in 1772 published seven new projections in his Anmerkungen und Zusätze zur Entwerfung der Land- und Himmelscharten. He was the first mathematician to analyse the general properties of projections and the first to discuss conformality and equal area as goals in their own right. Nearly every projection a cartographer reaches for today can be described by four decisions, the last of which Lambert was the first to frame.
First, a model of the Earth. A sphere is good enough for world maps; an ellipsoid is used for large-scale maps, because the Earth bulges at the equator. The geoid, the true sea-level surface, departs from the best-fitting ellipsoid by less than 100 m out of a radius of about 6.3 million m, so it is rarely used directly. Second, a surface: a cylinder, cone or plane, the three shapes that can be unrolled flat without further distortion. Third, an aspect: normal, with the surface's axis along the Earth's; transverse, at right angles; or oblique. Fourth, a property to protect: angles (conformal), area (equal-area), distance from chosen points (equidistant), or a balance of all three. The surface may touch the globe along one line or cut through it along two; these "standard lines" are where scale is exact, and placing them across the area being mapped keeps errors small.
| Purpose | Usual projection | Property kept | Named example |
|---|---|---|---|
| Sea navigation | Mercator | Angles (rhumb lines straight) | Printed marine charts |
| Aviation | Lambert conformal conic | Angles, near-straight great circles | US sectional charts, 33°N and 45°N |
| Topographic mapping | Transverse Mercator / UTM | Angles, scale within 1 part in 1,000 | 60 zones, 84°N to 80°S |
| Country statistics | Albers equal-area conic | Area | National Atlas of the United States |
| World statistics | Mollweide, Equal Earth | Area | NASA temperature anomaly map, 2018 |
| Polar regions | Polar stereographic | Angles | UPS grid, beyond 84°N and 80°S |
| Distance from a point | Azimuthal equidistant | Distance and direction from centre | UN emblem, 1946 |
| General world map | Winkel tripel | Balanced errors | National Geographic since 1998 |
Ocean Navigation: Mercator Charts From the Chart Table to the Harbour
Practically every printed marine chart uses the Mercator projection. The reason goes back to the Portuguese mathematician Pedro Nunes, who in the 1530s described the rhumb line, or loxodrome, a course that crosses every meridian at the same angle. Gerardus Mercator's 1569 world map, made "for the use of sailors", was constructed so that every rhumb line appears as a straight line. A navigator lays a parallel ruler between departure and destination, reads the bearing off the printed compass rose, and steers it.
The projection needed two later inventions before it worked at sea: tables for drawing it, which Edward Wright published in 1599, and a reliable way to find longitude, which arrived with the marine chronometer in the mid-18th century. A rhumb line is not the shortest route, though. For long ocean passages navigators plot the great circle on a gnomonic chart, where every great circle is straight, then transfer it to the Mercator chart as a series of short rhumb-line legs.
Flying Over San Francisco: Lambert Conformal Conic Sectionals
Pilots need angles too, but they fly great circles, not rhumb lines. Lambert's conformal conic, one of his 1772 seven, wraps a cone around the globe so that it cuts through two chosen parallels. On it, a straight line drawn between two airports closely approximates the great-circle route for typical flight distances, and bearings can still be measured with a protractor. The US Federal Aviation Administration's visual-flight sectional and terminal area charts use standard parallels at 33°N and 45°N, which run through the southern and northern parts of the contiguous United States.
The same projection suits any region that is wide from east to west. Metropolitan France's official projection, Lambert-93, uses standard parallels at 44°N and 49°N. The European Environment Agency recommends a Lambert conformal conic (ETRS89-LCC) for pan-European maps at 1:500,000 and smaller. In the United States, states that are long from west to east, such as Tennessee, define their State Plane coordinate grids on it.
Topographic Sheets Worldwide: The 60 Zones of UTM
For detailed maps of the land, modern national mapping systems use the transverse Mercator: the Mercator cylinder turned on its side so that it touches the globe along a meridian instead of the equator. Distortion stays tiny near that meridian, so the trick is to use many narrow strips. The Universal Transverse Mercator system divides the Earth between 84°N and 80°S into 60 zones, each 6° of longitude wide, and shrinks the central meridian of each to a scale of 0.9996. That limits linear distortion to about one part in 1,000 inside every zone.
NOAA credits the US Army Corps of Engineers with developing the system from the early 1940s, though German aerial photographs from 1943–44 carry a similar "UTMREF" grid. The US Army used the modern version from 1947. Datums matter as much as the projection: in North America, UTM coordinates on today's WGS84 can differ by up to 200 m from older ones based on NAD27, so a hiker's GPS and an old paper sheet must be set to the same datum.
Census and Land-Cover Maps: Albers Over the United States
As soon as a map shows something per unit of area, such as population density, forest cover or rainfall, it needs an equal-area projection, or the data are visually weighted toward whichever regions the projection enlarges. For a mid-latitude country wider than it is tall, the standard answer is the Albers equal-area conic, first described by Heinrich Christian Albers in 1805. Like Lambert's conic it uses two standard parallels, but it spaces the parallels to keep area rather than angles exact. Distortion is minimal between the two parallels. Some large countries use it as their official projection for census work, and most maps in the National Atlas of the United States were drawn on it.
Global Data on One Sheet: Mollweide and Equal Earth
For the whole world the equal-area choices are pseudocylindrical, with curved meridians. Karl Brandan Mollweide of Leipzig published his elliptical projection in 1805, and Jacques Babinet popularised it in 1857; it remains common for global distributions and for maps of the sky. Equal Earth, the 2018 projection of Bojan Šavrič, Bernhard Jenny and Tom Patterson, keeps area exact with simple, fast formulas. One of the first thematic maps published on it was NASA Goddard Institute for Space Studies' map of the global temperature anomaly for July 2018. It entered the open-source PROJ library that September and has registered EPSG codes, including EPSG:8857 centred on Greenwich. A UN General Assembly vote on 4 September 2026 backed equal-area world maps such as Equal Earth for most purposes other than navigation.
The Arctic, Antarctica and the UN Emblem: Maps Centred on a Pole
Cylinders fail at the poles, where Mercator's scale becomes infinite and UTM stops. Beyond 84°N and 80°S the military grid switches to the Universal Polar Stereographic system, a conformal projection onto a plane centred on the pole. Directions there behave strangely: grid north is defined along the prime meridian in the Antarctic and the 180th meridian in the Arctic, so in places grid north is true south.
When the purpose is distance rather than angle, the plane is used differently. On the azimuthal equidistant projection, distance and direction are both correct from the centre point. Adopted on 7 December 1946, the emblem of the United Nations uses a version centred on the North Pole and extending to 60°S, and radio operators aim antennas with maps centred on their own station.
Classroom Walls and Atlases: National Geographic's Winkel Tripel
A general reference map of the world has no single property to protect, so it is chosen largely on looks. In 1943 a New York Times editorial urged that the Mercator be discarded for something less deceptive, noting that it survived on walls partly because a rectangle fills a rectangular space, and in 1989 and 1990 seven North American geographic organisations recommended against any rectangular world map. The National Geographic Society moved to the Robinson projection in 1988 and to Oswald Winkel's 1921 tripel projection in 1998, which balances errors of area, direction and distance; many textbooks followed. Our guides to the Lambert conformal conic, the azimuthal equidistant projection and the Mollweide projection go deeper on the individual designs, and our piece on how map projections distort reality shows what each one gives up.
