How the Waitomo Glowworm Caves Formed: From Oligocene Sea to Glowing Grotto
Source: Wikimedia Commons
Natural Geography

How the Waitomo Glowworm Caves Formed: From Oligocene Sea to Glowing Grotto

A 1,300-metre, two-level cave cut by the Waitomo Stream into Oligocene limestone, now home to New Zealand’s glowworms. Here is how it formed, from the sea floor to the Glowworm Grotto.

Geography Worlds
March 11, 2026
Updated October 6, 2026
8 min read

The Waitomo Glowworm Caves are limestone caves in the northern King Country of New Zealand's North Island, about 12 km north-west of Te Kūiti and roughly two hours' drive south of Auckland. The main show cave, officially Waitomo Cave, has about 1,300 m of passages on two levels. They were dissolved out of Oligocene limestone, laid down on the sea floor about 30 million years ago, by the Waitomo Stream, which still flows through the lower level. On the ceiling of its Glowworm Grotto live thousands of larvae of Arachnocampa luminosa, a fungus gnat found only in New Zealand, which glow blue-green to lure prey. The cave is one of about 300 known limestone caves in the Waitomo district, and in 2013 it was described as the most visited glowworm display in the world, with about 500,000 visitors a year before the pandemic. The name comes from the Māori words wai, water, and tomo, a shaft or sinkhole: "water passing through a hole". The caves took shape in stages, beginning on an ancient sea floor.

Map marking the location of Waitomo Caves
Waitomo Caves, at 38.3°S, 175.1°E, on a Geography Worlds map drawn from Natural Earth boundary data (dashed lines mark disputed boundaries).

30 Million Years Ago: An Oligocene Sea Over a Sinking Zealandia

New Zealand stands on Zealandia, a mass of continental crust of about 4.9 million km² that broke away from Gondwana between 83 and 79 million years ago. Its crust is only about 20 km thick, thinner than most continents, so it rides lower on the mantle, and after the break-up it subsided. By about 23 million years ago, at the end of the Oligocene epoch, it may have been completely submerged. Today about 94% of it is still under the Pacific.

That flooding is the starting point for Waitomo. Where the King Country now stands there was a sea about 30 million years ago, and the remains of its animals piled up on the sea floor: corals, seashells, fish skeletons and huge numbers of tiny marine organisms. Over millions of years these layers were buried and pressed together into limestone. In the Waitomo district it is more than 200 m (660 ft) thick in places. The walls of the show cave are made of these fossils.

Earth Movements Lift the Waitomo Limestone Above the Sea

A cave can only form in limestone that has risen above the sea. About 25 million years ago, the southern part of Zealandia, on the Pacific Plate, began moving relative to the northern part on the Indo-Australian Plate. That boundary later produced the Alpine Fault and the Southern Alps, and to the north it fed the volcanoes of the Coromandel and Taupō zones. In the King Country, earth movements bent and buckled the hard limestone on the sea floor and pushed it up into ridges above sea level.

The uplift did two things. It put the limestone where rain could reach it, and the bending cracked it. Joints and fractures opened through the rock. Rainwater picks up carbon dioxide from the air and from the soil and becomes a weak carbonic acid, and it began working down those cracks, dissolving the calcium carbonate and widening each gap. The Waitomo Glowworm Cave sits in one of those uplifted ridges of Oligocene limestone. Our guide to how caves are formed follows the same chemistry step by step.

The Waitomo Stream Goes Underground and Cuts Two Levels

Once enough cracks had been widened, surface streams could sink into the rock. The Waitomo Stream, a tributary of the Waipā River (which in turn is the largest tributary of the Waikato), flows into the hillside here and runs through the cave. The point where it goes underground is now the cave's tourist exit, where boats come out into daylight.

Over a long period the stream cut down through the limestone, and the cave formed on two levels. The upper level is dry. Its large chambers probably mark an older route of the river, which was abandoned as the water found lower paths. The lower level is humid, and the Waitomo Stream still runs through it in a chain of lakes. The two entrances are 14 m (46 ft) apart vertically. A 16 m (52 ft) shaft known as the Tomo links the two levels and lets air move between them. Because the two entrances sit at different heights, the cave breathes like a chimney: air is drawn in or pushed out depending on whether it is warmer outside or inside, so the cave has little airflow on days when the two temperatures are close.

Dark water flowing out from under a limestone overhang hung with mossy stalactites and ferns, beside a small metal jetty
The Waitomo Stream at the boat exit of the Waitomo Glowworm Cave, where the stream enters the hillside. Photo: Bgabel, CC BY-SA 3.0, via Wikimedia Commons

Ruakuri, Aranui and Mangapohue: The Same Rock at Other Stages

The neighbouring caves show what the Glowworm Cave once was and what it may become. Ruakuri Cave carries a stream and glowworms like its neighbour. It is part of the same Waitomo streamway system, along with Lucky Strike and Tumutumu Cave. It was open to visitors from 1904 until 1988, when a legal and financial dispute closed it, and it reopened in 2005 with a spiral ramp at the entrance. Aranui Cave was found by accident in 1910, when Te Ruruku Aranui's dog fell down a hole while he was hunting. No stream runs through it and it has no glowworms. What it does have is delicate stalactites and stalagmites in many colours, the dry-cave stage the Glowworm Cave's upper level has already reached.

Some cave systems have gone further and collapsed. About 26 km west of the village, the Mangapohue Stream flows beneath the Mangapohue Natural Bridge, two limestone arches 17 m high that are the remnant of an ancient cave system that has since disintegrated. Gardner's Gut, in the Ruakuri Scenic Reserve, is the largest cave system in the North Island. Across the district, the same rock and the same water have produced hundreds of caves in every stage of growth and decay.

Volcanic Ash, Silt and the Speleothems of the Cathedral

Once the chambers were open, they began to fill in. Water seeping through the roof loses carbon dioxide when it reaches the cave air and leaves calcite behind. Drop by drop, this builds stalactites hanging from the ceiling and stalagmites rising from the floor, and water running down the walls lays down flowstone. The Blanket, in the chamber of the same name, is a stalactite sheet so thin that light shines through it, and it hangs like a blanket over a rail. In the Organ Loft a mass of stalagmites looks like the pipes of an organ.

The Cathedral is the largest chamber, about 40 m (130 ft) long and 13 m (43 ft) high. Its acoustics are good enough that singers and choirs have performed there. When the soprano Malvina Major sang to about 150 people in 1998, scientists measured the carbon dioxide, heat and humidity the audience produced. On the lower level, the Glowworm Grotto is about 30 m long and 10 m wide.

The youngest layer came from volcanoes. Quaternary volcanic ash covers the limestone across the region and washes into local streams as fine silt. A study in 1974 estimated that about 4 m (13 ft) of silty sediment had built up in the Glowworm Cave over the previous 90 years, narrowing the stream channel. After heavy rain the stream inside still rises, and it has sometimes flooded the lower level. Our guide to cave formations describes the speleothems in more detail.

Cathedral length40 m
Main passage39 m
Glowworm Grotto30 m
Tomo shaft16 m
Entrance drop14 m
Cathedral height13 m
Dimensions of the main features of the Waitomo Glowworm Cave, in metres; "entrance drop" is the vertical gap between its two entrances. Source: Wikipedia, "Waitomo Glowworm Cave"

Arachnocampa luminosa Colonises the Glowworm Grotto

The glowworms came last, and the cave's physical setup is what lets them live there. Arachnocampa luminosa lives in caves and on sheltered banks in native forest, wherever the air is damp enough to keep its silk traps from drying out. In the Glowworm Grotto and the Demonstration Chamber the stream supplies both the humidity and the food. Its main prey is a midge, Anatopynia debilis, whose larvae live in the mud and water of the cave stream, and the midges fly up from below into the glowworms' snares.

A larva is 3 to 5 mm long when it hatches and grows to 30 to 40 mm over several months. It hangs a silk tube from the ceiling and lowers up to 30 threads beaded with sticky droplets. Its light peaks at a wavelength of 487 nm and draws insects into the threads. The insect spends most of its life as a larva. The adults that follow live only for days, up to about 76 hours for females and 96 hours for males, and a female lays more than 100 eggs. Photo-monitoring between 2009 and 2013 showed that the glowworms in the cave glow on a 24-hour cycle and are brightest in the late afternoon. In Māori they are called titiwai, "lights reflected in water". Other animals share the habitat: harvestmen prey on the glowworms, and New Zealand longfin eels live in the Waitomo Stream at the cave exit.

A New Zealand glowworm larva lying along a rock surface with a row of hanging silk threads beaded with sticky droplets below it
A New Zealand glowworm larva, Arachnocampa luminosa, with its beaded silk fishing lines. Photo: Uwe Schneehagen, CC BY-SA 4.0, via Wikimedia Commons

The colony depends on that balance of air. In 1975 a new upper entrance door with a grille let air flow freely through the cave. The cave dried out and warmed up, a fungus that kills glowworms spread, and numbers fell so sharply that the cave closed from April to July 1979. Once the airflow was fixed, glowworms were moved in from other caves to rebuild the population.

From Tane Tinorau's Raft in 1887 to a Monitored Show Cave

Māori had known the cave for about a century, and the stream entrance was a good place to catch eels. But there is no evidence that anyone had gone inside before December 1887. That month Tane Tinorau, a local Māori, and the surveyor Fred Mace built a raft and floated in where the stream goes underground, lighting the way with candles, and found the Glowworm Grotto. Tinorau later found the upper entrance used by visitors today, and by 1889 he and his wife Huti were guiding paying groups. The government took the cave over in 1905 for £625, installed electric lighting in 1926, and returned the land to the descendants of the original owners in 1989. Under the 1990 Waitomo Deed of Settlement, they receive a share of the revenue.

Visitors now affect the cave's air, so it is watched closely. A Scientific Advisory Group monitors carbon dioxide, rock and air temperature, and humidity, and decides how many people may enter each day. Too much carbon dioxide forms carbonic acid that eats into the calcite, and too much ventilation dries out the glowworms. Lights for the tours encourage lampenflora, a film of algae and cyanobacteria that has to be removed carefully from the rock. For the wider landscape this ridge belongs to, see our guide to New Zealand's geography.
