Google Maps draws its flat map in Web Mercator (EPSG:3857, “WGS 84 / Pseudo-Mercator”), a version of Gerardus Mercator’s 1569 navigation projection that applies the simpler spherical formulas to GPS-style WGS 84 coordinates. Google adopted it in 2005 and it became the default for almost every web map, including Bing Maps, OpenStreetMap, Mapbox and Esri. It keeps local shapes and right angles correct and puts north up everywhere, which suits street maps and square image tiles. The price is size: areas inflate with distance from the equator, so Greenland looks as large as Africa, and the map has to stop at 85.051129° north and south. Since August 2018 the desktop version of Google Maps shows a 3D globe when you zoom all the way out, but every street-level view is still Web Mercator.
Quito and the equator: where the map tells the truth
Every Mercator map can be imagined as a cylinder wrapped around the globe and touching it along the equator. Along that line of contact the map’s scale is exactly right. Away from it, each parallel of latitude, which on the globe is a circle of radius R·cos φ, has to be stretched to the full width of the cylinder, so the east–west scale grows by a factor of 1/cos φ, the secant of the latitude. To keep shapes undistorted, the projection stretches the north–south scale by exactly the same factor at each latitude. That is what makes the projection conformal, and it is why sizes inflate while shapes survive.
Quito, Ecuador’s capital, is the capital city closest to the equator, which runs through the San Antonio parish in the north of the metropolitan area. At that latitude the scale factor is 1.0: a city block in Quito appears on Google Maps at its true size relative to the scale bar. The site also carries a reminder that pinning down coordinates is hard. The Monument to the Equator at the Ciudad Mitad del Mundo, 26 km north of central Quito, commemorates the French Geodesic Mission of 1736, yet GPS readings on the WGS 84 datum put the true equator about 240 m north of the line marked there.
Web Mercator adds two shortcuts of its own. It treats the Earth as a sphere with the equatorial radius of the WGS 84 ellipsoid, which makes the map very slightly larger than its nominal scale, and it feeds ellipsoidal coordinates into spherical formulas. That makes the projection marginally non-conformal, though the error is invisible to the eye. Confusing it with true ellipsoidal Mercator during coordinate conversion, however, can shift positions by as much as 40 km on the ground, and the US National Geospatial-Intelligence Agency has declared Web Mercator unacceptable for any official US Department of Defense use.
Duisburg, 1569: the sailor’s chart behind the app
The projection Google uses was announced more than four centuries before Google existed. Gerardus Mercator, a Flemish cartographer who had moved from Catholic Leuven to the more tolerant town of Duisburg in the Holy Roman Empire in 1552, published his new world map there in 1569. It measured 202 by 124 cm, was printed on eighteen separate sheets and carried the title Nova et Aucta Orbis Terrae Descriptio ad Usum Navigantium Emendata, “a new and augmented description of Earth corrected for the use of sailors”. The map carried fifteen framed legends of text, including an explanation of how to use the projection.
Its purpose was navigation. On Mercator’s grid a rhumb line, a course of constant compass bearing, is a straight line, so a navigator could lay a ruler between two ports and read off a heading. Mercator never explained how he constructed the spacing of his parallels, though his access to the loxodromic tables of the Portuguese mathematician Pedro Nunes probably helped. By the 18th century the projection had become the standard for sea charts. Its use for general world maps declined through the 20th century, then returned in the 21st with online mapping, for the reasons that a 1569 chart for sailors also suits a phone in a city street.
Manhattan’s 1811 grid: why a sailor’s map suits a street map
The Commissioners’ Plan of 1811 laid a rectangular grid of streets and lots over Manhattan from Houston Street up to 155th Street. On Google Maps those blocks meet at right angles, as they do on the ground, whether you look at the Upper West Side or the Lower East Side. That is the practical value of a conformal projection: at any zoom level, small shapes and the angles between streets are preserved, so a turn at a junction looks like the turn you will actually make. On an equal-area projection such as the Mollweide, the same grid would appear sheared anywhere far from the central meridian.
A second reason Mercator suits a web map is computational. Web Mercator turns the world between 85.051129° N and S into a perfect square, and the tiled web map that Google Maps helped popularise depends on that square. At zoom level 0 the whole world fits in a single 256 × 256 pixel tile. Each zoom level doubles the resolution in both directions, so one tile becomes four, then sixteen, and about 22 zoom levels are enough for most practical purposes, down to individual buildings. Tiles are numbered by zoom, column and row, can be rendered in advance and are fetched independently as you pan, so most of the screen stays in place while only the new edge loads. The spherical formulas are also simpler than the ellipsoidal ones used for large-scale paper charts.
Greenland and the Democratic Republic of the Congo: the size illusion
Zoom out on the flat map and the cost of conformality becomes obvious. Area is stretched by the square of the scale factor, 1/cos² φ, so at 60° latitude land appears four times its true area, and at 75° about fifteen times. Greenland spans roughly 59° to 83° N, which puts nearly all of it in the zone of heavy inflation; on Web Mercator it appears about as large as Africa.
The real figures are very different. Greenland covers about 2,166,086 km², of which the ice sheet takes about 81%. The Democratic Republic of the Congo, which straddles the equator and is barely inflated at all, covers about 2,345,408 km², a little more than Greenland. Africa as a whole, at about 30.3 million km², is around 14 times larger than Greenland. On Google Maps the Congo looks like a fraction of Greenland, and Africa looks roughly the same size, which is why this pair has become the standard demonstration of Mercator distortion and why the African Union has backed a campaign favouring the equal-area Equal Earth projection over Mercator.
None of this misleads a navigator or a driver, because any small area keeps its correct shape. What it cannot do is let your eye compare the sizes of two places at different latitudes.
Longyearbyen, Svalbard: a scale bar that has to change as you pan
Longyearbyen, capital of Svalbard and home to roughly 2,400 to 2,800 people, sits at about 78° N on the shore of Adventfjorden. There the Mercator scale factor is about 4.9, so a kilometre of coastline is drawn almost five times as long as a kilometre at the equator, and an area of land appears about 24 times larger. A single fixed scale bar cannot serve the whole world map: one centimetre on screen covers far less ground in Longyearbyen than in Quito at the same zoom level, so a scale bar on any Mercator map is only valid near the latitude it was computed for.
Nobody walking through Longyearbyen notices any of this, since the scale hardly shifts across one phone screen. The distortion only shows when you zoom out and set Svalbard beside somewhere further south.
The South Pole and the 85.051129° cut-off
Because the Mercator stretch grows without limit, the poles would sit at an infinite distance from the equator. A web map therefore has to stop somewhere, and Google chose the latitude that makes the map exactly square: 85.051129° north and south. At that edge the scale factor is about 11.6 and areas are inflated more than 130 times. Everything poleward of it, including the Amundsen–Scott South Pole Station on the Antarctic plateau at 2,835 m, cannot appear on the flat map at all, and what remains of Antarctica is drawn as a stretched white band along the bottom.
That limitation is one reason Google changed course in August 2018, when desktop Google Maps began showing a 3D globe at the widest zoom, dropping the flat Mercator view for the whole planet; users can still switch back to the 2D map in settings. Zoom in and the globe flattens into Web Mercator tiles again, because for streets, routes and buildings its strengths still win.
EPSG:900913 to EPSG:3857: the registry that refused Google’s map
The projection’s technical history is as contested as its look. The EPSG geodesy registry at first refused to give it a code, calling it technically flawed, so developers used the joke code 900913, which spells “GOOGLE” in numbers and was codified in the OpenLayers library. EPSG issued EPSG:3785 in 2008 and replaced it later that year with EPSG:3857, the identifier used today, officially named “WGS 84 / Pseudo-Mercator”. Although the projection is closely associated with Google, EPSG lists Microsoft as its information source.
